| GNSS | |
| Positioning system | GPS/BDS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165 dBm |
| Acquisition sensitivity | -148 dBm (cold) /-163 dBm (hot) |
| TTFF (open sky) | Avg. hot start ≤1sec
Avg. cold start ≤32sec |
| Cellular | |
| Communication network | LTE Cat 1 + GSM |
| Frequency | LTE FDD: B1/B3/B7/B8/B20/B28
LTE TDD: B34/B38/B39/B40/B41
GSM: 850/900//1800/1900MHz |
| Power | |
| Battery | 50mAh industrial-grade LiCo battery |
| Input voltage | 9-36VDC |
| Interface | |
| LED indication | GNSS (Blue), Cellular (Green) |
| Connector | OBDII port |
| SIM | Nano-SIM |
| USB | 1 x USB Type-C for configuration |
| Data storage | 16+16MB |
| Physical specification | |
| Dimensions | 51.0 x 50.0 x 22.0mm |
| Weight | 42g |
| Operating environment | |
| Operating temperature | -20°C to 70°C |
| Operating humidity | 5%～95%, non-condensing |
| Feature | |
| Voice monitoring range | ≤5 meters |
| Sensors | Accelerometer |
| Ignition detection | External Power Voltage |
| Scenarios | Vehicle movement alert, Speeding alert, Geo-fence, Voice-monitoring, Vehicle battery detection, Power supply disconnection |
| Driving behavior analysis | Harsh acceleration, Harsh braking, Harsh cornering, Collision |
