| Specification | |
| Network |
| Standard | 4G LTE Cat.4 |
| WiFi | 2.4GHz, Support AP Mode/STD Mode/WiFi Direct |
| Bluetooth | BLE 4.0 |
| Band | Eurasian Version
FDD-LTE: B1/B3/B7/B8/B20/B28A
TDD-LTE: B38/B40/B41
WCDMA: B1/B8
GSM: B3/B8 |
Northern American Version
FDD-LTE: B2/B4/B5/B12/B13/B14/B66
WCDMA: B2/B4/B5 |
Latin American Version
FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28
TDD-LTE: B40
WCDMA: B1/B2/B4/B5/B8
GSM: B2/B3/B5/B8 |
| Camera |
| Front Camera (Main) | 1920×1080/25FPS/F2.0/Full color/80° (HFoV) |
| Sub Camera (Optional) | CI02: 1280×720/15FPS/F2.5/Full color in daytime & monochrome in dim light/135° (HFoV) |
| Peripheral Camera (Optional ) | CI01: 1280×720/15FPS/F2.0/Full color in daytime & monochrome in dim light/100° (HFoV) |
| CI03: 1280×720/15FPS/F2.4/Full color in daytime & monochrome in dim light/119° (HFoV) |
| CD02: 1280×720/15FPS/F2.0/Monochrome/56° (HFoV) |
| CE01: 1280×720/15FPS/F2.0/Full color/IP67/125° (HFoV) |
| Video Format | .ts |
| Configuration |
| GNSS | GPS/BDS |
| Sensor | 3-axis |
| Microphone | Support |
| Speaker | Support |
| Interface | Type-C USB*1, SOS*1, RS232*1, TTL*1, Relay*1, Digital Input*2, CVBS-OUT*1 |
| Memory Support | TF Card (Up to 256GB*2) |
| SIM Card Type | Nano |
| LED Indication | Red (Power), Blue (Cellular), Green (GNSS) |
| Others |
| Power Supply | Power cable: B+/ACC/GND |
| Operating Voltage | DC 9–30V |
| Operating Temperature | –20°C to +70°C |
| Storage Temperature | –30°C to +85°C |
| Device Weight | 374g |
| Device Dimension | 114*113*33mm |
| Certifications | CE/FCC/PTCRB/RoHS |
