| GNSS | |
| Positioning system | GPS+BDS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec
Avg. cold start ≤32sec |
| Cellular | |
| Communication network | LTE Cat 1/GSM; LTE Cat M1/Cat NB2 |
| Frequency | LL303PRO-L
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
LTE-TDD: B40
GSM: B2/B3/B5/B8LL303PRO-E
LTE-FDD: B1/B3/B5//B7/B8/B20/B28
LTE-TDD: B38/B40/B41
GSM: B2/B3/B5/B8LL303PRO-A
Cat M1: B2/B4/B5/B12/B13/B25/B26/B66
Cat NB2: B2/B4/B5/B12/B13/B25/B66
GSM: B2/B3/B5/B8LL303PRO-GB:
Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66
Cat NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85
GSM: B2/B3/B5/B8 |
| Power | |
| Battery | 10,000mAh/3.7V industrial-grade Li-Polymer battery |
| Solar power | 5V/400mA (Standard Operating Voltage/Current @STC)
STC: Direct illumination with 38,000lux halogen lamp on the test bench. |
| Magnetic charger | 5V/2A |
| Working modes | Mode 1: Timing mode
Mode 2: Intelligent mode
Mode 3: Power-saving mode |
| Standby time | Up to 1 year in power-saving mode |
| Interface | |
| LED indication | Cellular (Green), Power (Red) |
| SIM | Nano-SIM |
| Tamper proof | Hall effect sensor |
| Physical specification | |
| Dimensions | 200x115x25mm |
| Weight | 423g |
| Operating environment | |
| Operating temperature | –20℃ to +70℃ |
| Operating humidity | 5%～95%, non-condensing |
| IP rating | IP67 |
| Feature | |
| Sensors | Accelerometer, Hall effect sensor |
| Scenarios | Low battery alert, Tamper alert, Vibrating Alert |
| Bluetooth | BLE 5.0 |
| RFID | 2.4GHz |
