| Positioning & Location | |
| Technology | GPS, BDS, GLONASS, LBS |
| Accuracy | <2.5m CEP |
| Tracking sensitivity | –165dBm |
| Acquisition sensitivity | –148dBm |
| TTFF (open sky) | Avg. hot start ≤ 2sec
Avg. cold start ≤ 38sec |
| Cellular | |
| Technology | LTE Cat 1 & GSM |
| Frequency | VL110C_EM: LTE-FDD: B1/B3/B7/B8/B20/B28 LTE-TDD: B34/B38/B39/B40/B41 GSM: B2/B3/B5/B8 VL110C_LA: LTE-FDD:：B1/B2/B3/B4/B5/B7/B8/B28 GSM: B2/B3/B5/B8 |
| Power | |
| Battery | 270mAh/3.7V industrial-grade Li-Polymer battery |
| Input voltage | 9–90VDC |
| Power consumption | Standby: <5mA |
| Operating environment | |
| Operating temperature | –20°C to +70°C |
| Operating humidity | 5% to 95%, non-condensing |
| IP rating | IP65 |
| Physical specification | |
| Dimensions | 94(L)*34(W)*15(H)mm |
| Weight | 44g |
| Interface | |
| LED indication | GNSS (Blue), Cellular (Green), Power (Red) |
| SIM | Nano-SIM |
| Digital I/Os | 1*ACC, 1*Relay |
| Analog I/Os | N/A |
| Voltage detection | N/A |
| Data storage | 3000+ GNSS data entries |
| USB | Type-C (for firmware upgrade) |
| Microphone | N/A |
| No. of relays | N/A |
| GNSS antenna | Internal |
| Bluetooth antenna | N/A |
| Serial ports | N/A |
| Feature | |
| Sensors | Accelerometer |
| Scenarios | Vehicle movement alert, Speeding alert, Geo-fence entry/exit, Vehicle battery detection, LTE jamming detection, GPS jamming detection |
| Driving behavior analysis (DBA) | Harsh acceleration, Harsh braking, Harsh cornering, Collision |
| Bluetooth | N/A |
| Configuration support | SMS, PC Tools, Tracksolid Pro, Type-C |
| Certification | CE/FCC/RoHS |
