| Positioning & Location | |
| Technology | GPS, BDS, LBS, BLE, WiFi |
| Accuracy | ＜2.5m CEP |
| Tracking sensitivity | –165dBm |
| Acquisition sensitivity | –148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec
Avg. cold start ≤32sec |
| Cellular | |
| Technology | 4G Cat 1, GSM |
| Frequency | PL200(L): FDD: B1/B2/B3/B4/B5/B7/B28 GSM: B2/B3/B5/B8 PL200(E): FDD: B1/B3/B7/B8/B20/B28: TDD: B38/B40/B41 GSM: B2/B3/B5/B8 |
| Power | |
| Battery | 2,000mAh/3.7V industrial-grade Li-Polymer battery (rechargeable) |
| Working modes | Mode 0: Step-count-based mode
Mode 1: Timing mode |
| Battery life | Up to 5 days |
| Interface | |
| LED indication | Power (Red), Notice (Green) |
| SIM | Nano-SIM |
| Memory capacity | 1000 GPS data entries |
| Button | 2*functional buttons; 1*panic button |
| USB | Magnetic |
| GNSS antenna | Internal |
| Bluetooth antenna | Internal |
| Feature | |
| Voice monitoring range | N/A |
| Sensors | Accelerometer |
| Scenarios | Power-on alert, Shutdown alert, Low battery alert, SOS alert, SIM card change alert, Geo-fence entry & exit alert |
| Specialties | Speaker, Microphone |
| Bluetooth | BLE 5.0 |
| RFID | N/A |
| Mount method | Lanyard |
| Configuration support | SMS, Online command |
| Certification | FCC、CE |
| Operating environment | |
| Operating temperature | –20℃ to +60℃ |
| Operating humidity | 5% to 95%, non-condensing |
| IP rating | IP65 |
| Physical specification | |
| Dimensions | 105.0 x 62.0 x 13.0mm |
| Weight | 81g |
