| Positioning & Location |
| Technology | GPS, GLONASS, BDS, AGPS, LBS |
| Accuracy | < 2.5m CEP |
| Tracking sensitivity | –165dBm |
| Acquisition sensitivity | –148dBm |
| TTFF (open sky) | Avg. hot start ≤ 2sec |
| Avg. cold start ≤ 38sec |
| Cellular |
| Technology | LTE Cat 1, 2G (GSM) |
| Frequency | VL111S_LA:
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28
GSM: B2/B3/B5/B8VL111S_EM:
LTE-FDD: B1/B3/B7/B8/B20/B28
LTE-TDD: B34/B38/B39/B40/B41
GSM: B2/B3/B5/B8 |
| Interface |
| LED indication | GNSS (Blue), Cellular (Green), Power (Red) |
| SIM | Nano-SIM |
| Digital I/Os | ACC, Buzzer (Optional) |
| Analog I/Os | N/A |
| Voltage detection | 0–90V |
| Memory capacity | 3000 GPS data entries |
| USB | Type-C |
| No. of onboard relays | 1 |
| GNSS antenna | Internal |
| Bluetooth antenna | Internal |
| Serial ports | N/A |
| Feature |
| Voice monitoring range | N/A |
| Sensors | Accelerometer |
| Scenarios | Vibrating alert, Speed alert, Tamper alert, Geo-fence entry/exit alert, Vehicle battery protection, Remote immobilization, Power disconnection alert, Low internal battery alert |
| Driving behavior analysis (DBA) | Harsh acceleration, Harsh braking, Harsh cornering, Collision |
| Bluetooth | BLE 5.0 |
| Configuration support | PC Tools, SMS, Tracksolid Pro |
| Certification | CE, FCC |
| Input voltage | DC 9-90V |
| Power consumption | Standby: < 5mA
Working: < 50mA |
| Operating environment |
| Operating temperature | –20℃ to +70℃ |
| Operating humidity | 5% to 95%, non-condensing |
| IP rating | IP66 |
| Physical specification |
| Dimensions | 92.0 x 28.0 x 14.0mm |
| Weight | 42.9g |
| Optional Configuration* |
| SM connector | Buzzer |
| SIM IC | 2.5 x 2.7mm onboard |
