GNSS | |
Positioning system | GPS+BDS+LBS |
Positioning accuracy | <2.5m CEP |
Tracking sensitivity | -162dBm |
Acquisition sensitivity | -160dBm |
TTFF (open sky) | Avg. hot start ≤1sec Avg. cold start ≤32sec |
Cellular | |
Communication network | LTE Cat 1/GSM |
Frequency | VL802-E: LTE-FDD: B1/B3/B7/B8/B20/B28 LTE-TDD: B34/B38/B39/B40/B41 GSM: 850/900/1800/1900MHzVL802-L: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 GSM: 850/900/1800/1900MHz |
Power | |
Battery | 1,000mAh/3.7V industrial-grade Li-Polymer battery |
Input voltage | 9-36VDC |
Interface | |
LED indication | GNSS (Green), Cellular (Blue), Power (Red) |
SIM | Micro-SIM |
Data storage | 16+16MB |
Digital inputs | ACC, SOS |
Digital outputs | Relay |
Configurable I/O | 2 special I/Os can be configured as extra digital inputs or outputs |
Analog detect | Support 0-5V |
Physical specification | |
Dimensions | 105 x 56 x 22mm |
Weight | 120g |
Operating environment | |
Operating temperature | –20℃ to +70℃ |
IP rating | IP65 |
Feature | |
Sensors | Accelerometer |
Scenarios | SOS alert, Speeding alert, Abnormal vibration alert, Fatigue driving alert |
