| GNSS | |
| Positioning system | GPS+BDS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec
Avg. cold start ≤32sec |
| Cellular | |
| Communication network | LTE Cat 1/GSM |
| Frequency | VL103M (L)
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28
GSM: B2/B3/B5/B8VL103M (E)
LTE-FDD: B1/B3/B7/B8/B20/B28
LTE-TDD: B34/B38/B39/B40/B41
GSM: B2/B3/B5/B8 |
| Power | |
| Battery | 270mAh/3.7V industrial-grade Li-Polymer battery |
| Input voltage | 9-90VDC |
| Interface | |
| LED indication | GNSS (Blue), Cellular (Yellow), Power (Red) |
| SIM | Micro-SIM |
| Data storage | 16+16Mb |
| Digital inputs | ACC, SOS |
| Digital outputs | Relay, IO for buzzer/horn output |
| Physical specification | |
| Dimensions | 92.0 x 40.0 x 20.0mm |
| Weight | 55g |
| Operating environment | |
| Operating temperature | –20℃ to +70℃ |
| IP rating | IP66 |
| Feature | |
| Sensors | Accelerometer |
| Scenarios | Vibrating alert, Speeding alert, SOS call, Tamper alert, Cover removal alert, Geo-fence entry/exit alert, Vehicle battery detection |
