| GNSS | |
| Positioning system | GPS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec
Avg. cold start ≤40sec |
| Cellular | |
| Communication network | LTE/EGPRS |
| Frequency | LTE Cat M1/NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28/B66
EGPRS: 850/900/1800/1900 MHz |
| Power | |
| Battery | 10,000mAh/3.7V industrial-grade Li-Polymer battery |
| Working modes | Mode 0: Standby mode
Mode 1: Tracking mode
Mode 2: Power-saving mode |
| Standby time | Up to 3 years in power-saving mode |
| Interface | |
| LED indication | 1 status indicator (Red), 4 battery indicators (Blue) |
| SIM | Standard-SIM |
| Data storage | 32+32Mb |
| Tamper proof | Light sensor |
| Physical specification | |
| Dimensions | 109.0 x 61.0 x 30.5mm |
| Weight | 297g |
| Operating environment | |
| Operating temperature | –20℃ to +70℃ |
| Operating humidity | 5%～95%, non-condensing |
| IP rating | IP65 |
| Feature | |
| Certificates | FCC, CE, PTCRB, AT&T, TELEC |
| Sensors | 3-Axis Accelerometer |
| Scenarios | Low battery alert, Tamper alert, Vibrating Alert, Over-speed alert, Cover removal alert, Installation alert, Geo-fence |
