| Image Sensor | Panorama: 1/2.9" CMOS · Detail: 1/2.9" CMOS |
| Max Resolution | Panorama: 3MP (2304×1296 @20fps) · Detail: 3MP (2304×1296 @20fps) |
| Min. Illumination | Color: 0.02 Lux @ F1.6 (AGC ON) |
| Shutter Time | 1s – 1/100,000s |
| Day & Night | Fixed IR-cut |
| WDR | DWDR |
| S/N Ratio | ≥52 dB |
| Angle Adjustment | Panorama: Pan -60°~60°, Tilt 5°~15° · Detail: Pan 0°~345°, Tilt 0°~90° |
| Lens Type | Fixed focal lens |
| Focal Length | Panorama: 4 mm · Detail: 4 mm |
| Aperture | F1.6 (Fixed) |
| Field of View | H: 79.6° · V: 42.5° · D: 91.7° (Panorama & Detail) |
| DORI Distance | Detect: 59.26 m · Observe: 23.52 m · Recognize: 11.85 m · Identify: 5.93 m |
| Pan Speed | 30°/s |
| Tilt Speed | 25°/s |
| Presets | 64 |
| IR LEDs | Panorama: 4 · Detail: 4 |
| IR Distance | Up to 30 m |
| White LEDs | Panorama: 4 · Detail: 4 |
| White Light Distance | Up to 20 m |
| Alarm Flash | Red & Blue Alarm Flash |
| Video Compression | S+265 / H.265 |
| Video Bit Rate | 1.2 Mbps |
| Audio Compression | G.711A |
| Audio Sampling Rate | 16 kHz |
| Main Stream | Panorama & Detail: PAL 20fps (2304×1296) |
| Sub Stream | PAL 15fps (704×576) |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto |
| OSD | 48×48 · Lattice |
| Smart Alarm | Human & Vehicle Detection |
| Auto-Tracking | Yes |
| Network Protocols | TCP/IP, UDP, ICMP, DNS, NTP, IPv4, SSH, Unicast |
| Remote Connections | ≤2 |
| Mobile App | EasyLive Plus |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
| Storage | microSD / microSDHC / microSDXC up to 256GB |
| Operating Temperature | -20°C ~ 50°C |
| Operating Humidity | ≤95% RH |
| Storage Temperature | -20°C ~ 50°C |
| Power Supply | DC 5V ±25%, Max 10W |
| Protection | IP65 · Surge 500V · ESD 6000V |
| Dimensions | 183 × 105 × 202 mm |
| Package Dimensions | 315 × 225 × 180 mm |
| Gross Weight | 1.66 kg |
