| Image Sensor | 1/2.8" CMOS |
| Minimum Illumination | Color: 0.02 Lux @ (F1.6, AGC ON); B/W: 0 Lux with IR |
| Shutter Time | 1s – 1/100000s |
| Day & Night | IR-cut filter with Auto Switch (ICR) |
| Smart IR | Yes |
| WDR | DWDR |
| Signal-to-Noise Ratio | >48 dB |
| Angle Adjustment | Pan: 0–345° / Tilt: 0–90° |
| Lens Type | Fixed focal lens |
| Focal Length | 4 mm |
| Lens Mount | M12 |
| Aperture | F1.6 (Fixed) |
| Field of View | H: 86.8° / V: 46.1° / D: 99.7° |
| DORI Distance | Detect: 65.31 m / Observe: 25.92 m / Recognize: 13.06 m / Identify: 6.53 m |
| Pan Speed | 30°/s |
| Tilt Speed | 25°/s |
| Presets | 255 |
| IR LEDs | 4 |
| IR Distance | Up to 50 m |
| IR Wavelength | 850 nm |
| White LEDs | 4 |
| White Light Distance | Up to 15 m |
| Red & Blue Alarm Flash | Yes |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H |
| Video Bit Rate | 32 kbps – 4 Mbps |
| Audio Compression | G.711A / G.711U |
| Audio Sampling Rate | 8 kHz / 16 kHz |
| Maximum Resolution | 3 MP (2304 × 1296 @ 20 fps) |
| Main Stream | PAL/NTSC up to 20 fps (2304×1296, 1920×1080, 1280×720, etc.) |
| Sub Stream | PAL/NTSC up to 20 fps |
| BLC / HLC | Yes / Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Presets |
| OSD | Up to 48 characters per line |
| Privacy Mask | 4 static black areas |
| Defog | Yes |
| Video Analytics | Smart Alarm |
| Auto-Tracking | Yes |
| Exception Alarms | Disk Full, Disk R/W Error, IP Conflict, Network Disconnection |
| Linkage Method | Trigger Sound, Warmlight, Recording, Capture |
| ANR | Yes |
| Network Protocols | RTSP, HTTP, TCP, UDP, ICMP, DHCP, DNS, NTP, TLS v1.2, IPv4, SSH |
| System Compatibility | ONVIF (Profile S/T), SDK, CGI, Milestone |
| Remote Connection | ≤ 2 users |
| Client Software | Easy7 VMS |
| Mobile Client | EasyLive Plus |
| Web Browser | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Wi-Fi Standard | IEEE 802.11 b/g/n |
| Wi-Fi Frequency | 2.4 GHz |
| Wi-Fi Range | Up to 30 m (environment dependent) |
| Wi-Fi Security | WPA-PSK / WPA2-PSK |
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
| Reset Button | Yes |
| On-board Storage | microSD / microSDHC / microSDXC up to 256 GB |
| Operating Temperature | -30°C ~ 60°C |
| Operating Humidity | ≤95% RH |
| Storage Temperature | -30°C ~ 60°C |
| Power Supply | DC 12V ±25%, Max. 12W |
| Protection | Surge 4000V, ESD 6000V, IP66 |
| Dimensions | 104.5 × 125.5 × 140 mm |
| Package Dimensions | 135 × 135 × 190 mm |
| Gross Weight | 0.53 kg
|
