| Camera | |
| Image Sensor | 1/2.9″CMOS |
| Min. Illumination | Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR |
| Shutter Time | 1s~1/100000s |
| Day&Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | 120dB |
| S/N | >50dB |
| Angle Adjustment | 0~360°(P); 0~75°(T); 0~360°(R) |
| Lens | |
| Lens Type | Fixed focal lens |
| Focal Length | 2.8mm |
| Lens Mount | M12 |
| Aperture Range | F1.6 |
| Aperture Type | Fixed |
| Field of View | 103.8°(H); 56.8°(V); 120.4°(D) |
| DORI Distance | Detect:40.0m Observe:15.87m Recognize:8.0m Identify:4.0m |
| Illuminator | |
| IR LEDs | 2 |
| IR Distance | Up to 30m |
| Wavelength | 850nm |
| White LEDs | 2 |
| Whitelight Distance | 15m |
| Compression Standard | |
| Video Compression | S+265/H.265/H.264B/H.264M/H.264H |
| Video Bit Rate | 32k~4Mbps |
| Audio Compression | G.711A/G.711U |
| Audio Sampling Rate | 8kHz/16kHz |
| Image | |
| Max. Resolution | 2MP,1920×1080@25fps |
| Main Stream | PAL:20fps(1920×1080) NTSC:20fps(1920×1080) |
| Sub Stream | PAL:20fps(704×576) NTSC:20fps(704×480) |
| BLC | Yes |
| HLC | Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto |
| OSD | Overlay of additional characters in 5 regions, 2 lines, with a maximum of 127 characters or 42 Chinese characters per region; 16*16/32*32/48*48 |
| Feature | |
| Exceptions Alarm | Disk Full; Disk R/W Error |
| Linkage Method | Trigger Sound; Trigger Warmlight; Trigger Recording; Trigger Capture |
| Network | |
| Protocols | TCP/IP; UDP; ICMP; DHCP; DNS; NTP; IPv4; SSH; Unicast |
| System Compatibility | SDK |
| Remote Connection | ≤2 |
| Moblie Client | EasyLive Plus |
| Wi-Fi | |
| Transmission Distance | Up tp 50m( based on actual environment) |
| Wireless Standard | IEEE802.11b/ 802.11g/802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | 20/40MHz |
| Wi-Fi Security | WPA-PSK/WPA2-PSK |
| Interface | |
| Built-in Mic | Yes |
| Built-in Speaker | Yes |
| Reset Button | Yes |
| On-board Storage | Support microSD/microSDHC/microSDXC card,up to 256GB |
| General | |
| Operating Temperature | -10℃~50℃(14℉~122℉) |
| Operating Humidity | ≤95%RH |
| Storage Temperature | -10℃~50℃(14℉~122℉) |
| Storage Humidity | 10%~95%RH(non-condensing) |
| Power Supply | DC5V/2A |
| Protection | Surge500V; ESD6000V; IP65 |
| Boundary Dimensions | 80(L)44W)73(H)mm |
| Package Dimensions | 146(L)83(W)108(H)mm |
| GrossWeight | 0.38kg |
