| Image Sensor | 1/2.8" CMOS |
| Minimum Illumination | Color: 0.002 Lux @ (F1.6, AGC ON); B/W: 0 Lux with IR |
| Shutter Time | 1s ~ 1/100000s |
| Day & Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | 120 dB |
| Signal-to-Noise Ratio | >42 dB |
| Angle Adjustment | Pan: 0–345° / Tilt: 0–90° / Rotate: 0–350° |
| Lens Type | Motorized |
| Focal Length | 2.7 – 13.5 mm |
| Lens Mount | Φ14 |
| Aperture | F1.6 (Fixed) |
| Field of View | H: 106.7°–31.5° / V: 57.3°–17.8° / D: 130.9°–34.8° |
| DORI Distance | Detect: 77–331 m / Observe: 30.55–131 m / Recognize: 15.5–66 m / Identify: 7.5–33 m |
| IR LEDs | 18 |
| IR Distance | Up to 50 m |
| IR Wavelength | 850 nm |
| White LEDs | 18 |
| White Light Distance | Up to 15 m |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H / Motion JPEG |
| Video Bit Rate | 32 kbps – 16 Mbps |
| Audio Compression | G.711A / G.711U / ADPCM_D / AAC_LC |
| Audio Sampling Rate | 8 kHz / 32 kHz / 48 kHz |
| Maximum Resolution | 8 MP (3840 × 2160 @ 20 fps) |
| Main Stream | PAL: up to 25 fps / NTSC: up to 30 fps |
| Sub Stream | Supported |
| Third Stream | Supported |
| BLC / HLC | Yes / Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Presets |
| ROI | 8 static areas |
| Corridor Mode | Yes |
| OSD | Up to 127 characters, multi-region |
| Picture Overlay | 1 × BMP (200 × 200, 24-bit) |
| Privacy Mask | 4 areas |
| Defog | Yes |
| General Alarms | Motion Detection, Mask Alarm, Alarm Input |
| Exception Alarms | Voltage, Disk Error, IP/MAC Conflict, Network Issues |
| Linkage Methods | Email, Sound, Recording, Capture, Alarm Output |
| Video Analytics | Human & Vehicle Classification, Tripwire, Perimeter |
| Behavior Analysis Rules | 8 |
| ANR | Yes |
| Protocols | RTSP, RTMP, HTTP/HTTPS, TCP/UDP, SNMP, DHCP, DNS, IPv4/IPv6, FTP, SFTP |
| Compatibility | ONVIF (Profile S/T/G/M), SDK, CGI, Milestone |
| Remote Connection | ≤ 2 users |
| Client Software | Easy7 VMS |
| Mobile App | EasyLive Plus |
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Audio I/O | 1× In / 1× Out |
| Alarm I/O | 1× In / 1× Out |
| Built-in Microphone | Yes |
| Reset Button | Yes (Built-in) |
| Local Storage | microSD up to 512 GB |
| RTC | Yes |
| Operating Temperature | -35°C ~ 65°C |
| Power Supply | DC 12V ±25%, Max. 8W / PoE IEEE 802.3af, Max. 9W |
| Protection | Surge 4000V, ESD 6000V, IP67, IK10 |
| Dimensions | 143 × 143 × 123 mm |
| Gross Weight | 1.138 kg |
