·8*10/100Mbps PoE Ports + 2*100/1000Mbps RJ45 Uplink Ports

·Comply with IEEE 802.3、IEEE 802.3u、IEEE802.3ab、 IEEE802.3x standard

·Ethernet port supports 10/100/1000Mbps adaptive

·Support POE Priority(QOS)：1>2>3>4>5>6>7>8（The port in front has higher priority）

·Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts back pressure standard ·Support Port Auto-flip(Auto MDI/MDIX)

·Adopting store-and-forward switching mechanism

·Panel indicator monitoring status and help failure analysis

·With three gears and one key intelligent dip switch，support VLAN、Default、Extend three modes

·Support port lightning surge: common mode 4KV (level C); Electrostatic ESD: air 8KV, contact 6KV (level C)
