| Model | POE220 |
| No. of channels | 2 |
| Pass Through Data Ratesi | 10/100/1000Mbps |
| Power over Ethernet Output | Pin Assignment and Polarity: 1/2 (-), 3/6 (+) |
| Output Power Voltage: 54VDC |
| User Port Power: 30W max |
| Input Power Requirements | AC Input Voltage: 100 to 240 VAC |
| AC Input Current: 0.8A 100-240 VAC |
| AC Frequency: 50 to 60 Hz |
| Dimensions | 131mm x 70mm x 40mm |
| Indicators | System Indicator: AC Power |
| User Indicator: Channel Power |
| Connectors | Shielded RJ-45, EIA 568A and 568B |
| Protection | Over current protection |
| Over load protection |
| Over voltage protection |
| Anti-interference protection |
| Environmental Conditions | Operating Ambient Temperature: 0 to 40℃ |
| Operating Humidity: Maximum 80%, Non-condensing |
| Storage Temperature:-20 to 70℃ |
| Storage Humidity: Maximum 80%, Non-condensing |
