| Hardware Features | Highlights | CPU: 880 MHz Dual-Core Processor |
| Flash: 16 MB (128 Mbit) |
| DDR: 128 MB (1 Gbit) |
| Interface | 1× Gigabit Ethernet (RJ-45) Port (Support IEEE802.3af PoE and Passive PoE) |
| 1× Reset Button |
| Power Supply | 802.3af/at PoE |
| 24-57 V Passive PoE (+4,5pins; -7,8pins) |
| Dimensions ( W×D×H ) | AP Body: 240×100×53.7 mm
Antennas: 197.5×21.6×15.5 mmHeight of AP with Antennas installed: 438 mm |
| Antenna Type | 2× Detachable Omni-directional Antennas |
| Mounting | Pole/Wall Mounting (Kits included) |
| Wireless Function | Wireless Standard: | Wi-Fi 5 (802.11ac/n/g/b/a) |
| Frequency: | 5 GHz, 2.4 GHz |
| Signal Rate: | 5 GHz: Up to 867 Mbps |
| 2.4 GHz: Up to 300 Mbps |
| Bandwidth | 20/40/80 MHz |
| Wireless Functions | Multiple SSID |
| Enable/Disable Wireless Radio |
| Transmit Power Control |
| QoS (WMM) |
| Mesh (Requires a Cudy Mesh unit/Mesh router/AC as the gateway with firmware newer than 15.28) |
| Band Steering |
| MU-MIMO |
| Beamforming |
| Rate Limit |
| Reboot Schedule |
| Wireless Schedule |
| Wireless Encryption | WPA-PSK |
| WPA2-PSK |
| WPA-PSK/WPA2-PSK |
| Security | Access Control |
| Mac Filtering |
| Wireless Isolation Clients |
| Weather-Proof | Water-Proof | IP65 (Protection against any dust and low-pressure water from any directions) |
| Lightning Protection | 4 KV Lightning/Surge protection at the Ethernet port |
| Operating Mode | Access Point Mode |
| Router Mode |
| RE Mode |
| WISP Mode |
| Package Contents | Outdoor Wireless Access Point |
| 2× Detahcable Wi-Fi Antennas |
| 48 V / 0.3 A Passive PoE Adapter |
| Mounting Kits |
| Installation Guide |
| Environment | Operating Temperature: -20~60 °C (-10~140°F) |
| Storage Temperature: -40–70 °C (-40–158 °F) |
| Operating Humidity: 10–90% RH non-condensing |
| Storage Humidity: 5–90% RH non-condensing |
| System Requirements | Operating system that supports network/Wi-Fi connectivity, such as Windows, Android, macOS, iOS, or Linux |
