Specifications

Details
Product code	RBwAPG-5HacT2HnD
Architecture	MIPSBE
CPU	QCA9556
CPU core count	1
CPU nominal frequency	720 MHz
Dimensions	185 x 85 x 30 mm
RouterOS license	4
Operating System	RouterOS
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 100'000 hours at 25C
Tested ambient temperature	-40°C to 70°C
Suggested price	$89.00

Wireless capabilities

Details
Wireless 2.4 GHz Max data rate	300 Mbit/s
Wireless 2.4 GHz number of chains	2
Wireless 2.4 GHz standards	802.11b/g/n
Antenna gain dBi for 2.4 GHz	2
Wireless 2.4 GHz chip model	QCA9556
Wireless 2.4 GHz generation	Wi-Fi 4
Wireless 5 GHz Max data rate	1300 Mbit/s
Wireless 5 GHz number of chains	3
Wireless 5 GHz standards	802.11a/n/ac
Antenna gain dBi for 5 GHz	2
Wireless 5 GHz chip model	QCA9880
Wireless 5 GHz generation	Wi-Fi 5
WiFi speed	AC1600

Ethernet

Details
10/100/1000 Ethernet ports	1

Powering

Details
Number of DC inputs	1 (PoE-IN)
Max power consumption	12 W
Cooling type	Passive
PoE in	802.3af/at
PoE in input Voltage	11-57 V

Certification & Approvals

Details
Certification	CE, FCC, IC, EAC, ROHS
IP	IP54

Other

Details
PCB temperature monitor	Yes
Voltage Monitor	Yes

Wireless specifications

2.4 GHz	Transmit (dBm)	Receive Sensitivity
1MBit/s	25	-95
11MBit/s	25	-90
6MBit/s	25	-95
54MBit/s	23	-80
MCS0	25	-95
MCS7	22	-74

5 GHz	Transmit (dBm)	Receive Sensitivity
6MBit/s	25	-96
54MBit/s	25	-81
MCS0	25	-96
MCS7	24	-77
MCS9	23	-72
