| Image Sensor | Panorama: 1/2.9" CMOS • Detail: 1/2.9" CMOS |
| Minimum Illumination | Color: 0.0004 lux @(F1.0, AGC ON) |
| Shutter Time | 1s – 1/100000s |
| Day / Night | Fixed IR-cut |
| WDR | DWDR |
| S/N Ratio | ≥52 dB |
| Angle Adjustment | Panorama: -60°~60° (Pan), 5°~15° (Tilt) • Detail: 0~345° (Pan), 0~90° (Tilt) |
| Lens Type | Fixed focal lens |
| Focal Length | Panorama: 4 mm • Detail: 4 mm |
| Lens Mount | M12 |
| Aperture | F1.0 (Fixed) |
| Field of View | H: 79.8° • V: 44.7° • D: 90.8° |
| DORI Distance | Detect: 57.14 m • Observe: 22.68 m • Recognize: 11.43 m • Identify: 5.71 m |
| Pan Speed | 30°/s |
| Tilt Speed | 25°/s |
| Presets | 64 |
| IR LEDs | Panorama: 4 • Detail: 4 |
| IR Distance | Up to 30 m |
| White LEDs | Panorama: 4 • Detail: 4 |
| White Light Distance | Up to 20 m |
| Alarm Flash | Red & Blue Alarm Flash |
| Video Compression | S+265 / H.265 |
| Video Bit Rate | 1.2 Mbps |
| Audio Compression | G.711A |
| Audio Sampling Rate | 16 kHz |
| Max Resolution | 3MP (2304 × 1296) @ 20 fps |
| Main Stream | PAL: 20 fps (2304 × 1296) |
| Sub Stream | PAL: 15 fps (704 × 576) |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto |
| OSD | 48 × 48, Lattice |
| Smart Alarm | Human & Vehicle Detection |
| Exception Alarm | Disk Full, Disk R/W Error |
| Linkage Actions | Sound, White Light, Recording, Snapshot |
| Auto Tracking | Supported |
| Network Protocols | TCP/IP, UDP, ICMP, DNS, NTP, IPv4, SSH, Unicast |
| Remote Connections | ≤2 |
| Mobile App | EasyLive Plus |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
| On-board Storage | microSD/SDHC/SDXC up to 256 GB |
| Operating Temperature | -20°C ~ 50°C |
| Operating Humidity | ≤95% RH |
| Power Supply | DC 5V ±25%, Max. 10 W |
| Protection | Surge 500V • ESD 6000V • IP65 |
| Dimensions | 183 × 105 × 202 mm |
| Package Dimensions | 315 × 225 × 180 mm |
| Gross Weight | 1.66 kg |
