| Image Sensor | 1/2.7" CMOS |
| Minimum Illumination | Color: 0.02 Lux @ (F1.6, AGC ON) / B&W: 0 Lux with IR |
| Shutter Time | 1s – 1/100000s |
| Day & Night | IR-cut filter with Auto Switch (ICR) |
| Smart IR | Yes |
| WDR | True WDR |
| Signal-to-Noise Ratio | >52 dB |
| Angle Adjustment | Pan: 0–360° / Tilt: 0–80° / Rotate: 0–360° |
| Lens Type | Fixed focal lens |
| Focal Length | 4 mm |
| Lens Mount | M12 |
| Aperture | F1.6 (Fixed) |
| Field of View | H: 95.1° / V: 49.2° / D: 111.1° |
| DORI Distance | Detect: 80 m / Observe: 31.8 m / Recognize: 16 m / Identify: 8 m |
| IR LEDs | 2 |
| IR Distance | Up to 30 m |
| IR Wavelength | 850 nm |
| White LEDs | 2 |
| White Light Distance | Up to 15 m |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H |
| Video Bit Rate | 32 kbps – 6 Mbps |
| Audio Compression | G.711A / G.711U |
| Audio Sampling Rate | 8 kHz |
| Maximum Resolution | 6 MP (3200 × 1800 @ 30 fps) |
| Main Stream | PAL: 25 fps / NTSC: 30 fps (up to 3200 × 1800) |
| Sub Stream | PAL: 25 fps / NTSC: 30 fps |
| BLC / HLC | Yes / Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Presets |
| OSD | Up to 96×96, Lattice |
| Privacy Mask | 4 areas |
| Defog | Yes |
| General Alarm | Smart Alarm (Human & Vehicle Detection) |
| Exception Alarm | IP Address Conflict |
| Linkage Method | Trigger Capture |
| Network Protocols | RTSP, HTTP, TCP, UDP, ICMP, DHCP, DNS, NTP, IPv4, SSH, Unicast |
| System Compatibility | ONVIF (Profile S/T), SDK, CGI, Milestone, P2P |
| Remote Connection | ≤ 2 users |
| Client Software | Easy7 VMS |
| Mobile Client | EasyLive Plus |
| Web Browser | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Built-in Microphone | Yes |
| Web Client Language | 12 languages |
| Operating Temperature | -30°C ~ 60°C |
| Operating Humidity | ≤95% RH |
| Storage Temperature | -30°C ~ 60°C |
| Storage Humidity | 10% ~ 95% RH |
| Power Supply | PoE IEEE 802.3af |
| Max Power Consumption | 5 W |
| Protection | Surge 4000V, ESD 6000V, IP67 |
| Dimensions | 164 × 73 × 73 mm |
| Package Dimensions | 180 × 90 × 95 mm |
| Gross Weight | 0.3 kg |
