| Image Sensor | 1/2.7" CMOS |
| Minimum Illumination | Color: 0.0004 Lux @ (F1.0, AGC ON); B/W: 0 Lux with IR |
| Shutter Time | 1s – 1/100000s |
| Day & Night | Fixed IR-cut |
| WDR | True WDR 120 dB |
| Signal-to-Noise Ratio | >39 dB |
| Angle Adjustment | Pan: 0–360° / Tilt: 0–90° / Rotate: 0–360° |
| Lens Type | Fixed focal lens |
| Focal Length | 2.8 mm |
| Lens Mount | M12 |
| Aperture | F1.0 (Fixed) |
| Field of View | H: 109° / V: 59° / D: 125.4° |
| DORI Distance | Detect: 56 m / Observe: 22 m / Recognize: 11 m / Identify: 5.6 m |
| White LEDs | 2 |
| White Light Distance | Up to 15 m |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H |
| Video Bit Rate | 32 kbps – 6 Mbps |
| Audio Compression | G.711A / G.711U / ADPCM_D |
| Audio Sampling Rate | 8 kHz / 32 kHz / 48 kHz |
| Maximum Resolution | 5 MP (3072 × 1728 @ 30 fps) |
| Main Stream | PAL: up to 25 fps / NTSC: up to 30 fps |
| Sub Stream | PAL/NTSC up to 30 fps |
| BLC / HLC | Yes / Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Presets |
| ROI | 8 rectangular static areas |
| OSD | Up to 48 characters per line |
| Privacy Mask | 4 static black areas |
| Defog | Yes |
| General Alarms | Motion Detection, Mask Alarm |
| Exception Alarms | Disk Full, Disk R/W Error, IP Conflict, Network Disconnection |
| Linkage Method | Recording, Capture, Notify Surveillance Center |
| Video Analytics | Human & Vehicle Classification, Tripwire, Perimeter |
| Behavior Analysis Rules | 2 rules per scene |
| ANR | Yes |
| Network Protocols | RTSP, HTTP/HTTPS, TCP, UDP, SNMP, DHCP, DNS, NTP, TLS v1.2, IPv4, SSH, FTP, Multicast |
| System Compatibility | ONVIF (Profile S/T/G), SDK, CGI, Milestone |
| Remote Connection | ≤ 2 users |
| Client Software | Easy7 VMS |
| Mobile Client | EasyLive Plus |
| Web Browser | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Built-in Microphone | Yes |
| Reset Button | Yes |
| On-board Storage | microSD / microSDHC / microSDXC up to 512 GB |
| RTC | Yes |
| Operating Temperature | -35°C ~ 65°C |
| Operating Humidity | ≤95% RH |
| Storage Temperature | -35°C ~ 65°C |
| Power Supply | DC 12V ±25%, Max. 6W; PoE IEEE 802.3af, Max. 7W |
| Protection | Surge 4000V, ESD 6000V, IP67 |
| Dimensions | 161 × 68 × 66 mm |
| Package Dimensions | 215 × 95 × 120 mm |
| Gross Weight | 0.44 kg |
