1XPON+2.5GbE ONU

Dimension

82mm×82mm×25mm(L×W×H)

Net weight

0.085Kg

Operating condition

Operating temp: -10 ~ +55°C

Operating humidity: 5 ~ 95% (non-condensing)

Storing condition

Storing temp: -40 ~ +70°C

Storing humidity: 5~ 95%  (non-condensing)

Power adapter

DC 12V, 0.5A, external AC-DC power adaptor

Power supply

≤4W

Interfaces

2.5GbE

Indicators

SYS, LINK/ACT, REG

○ Interface parameter

PON interface

1 XPON port(EPON PX20+ & GPON Class B+)

SC single mode, SC/UPC connector

TX optical power: 0～+4dBm

RX sensitivity: -27dBm

Overload optical power: -3dBm(EPON) or  -8dBm(GPON)

Transmission distance: 20KM

Wavelength: TX 1310nm, RX1490nm

LAN interface

1*2.5GbE, Auto-negotiation RJ45 connectors

○ Function Data

XPON Mode

Dual mode,Auto-access to EPON/GPON OLT

Uplink Mode

Bridging and Routing Mode

Abnormal protection

Detecting Rogue ONU, Hardware Dying Gasp

Firewall

DDOS, Filtering Based on ACL/MAC/URL

○ Product Feature

Basic

Support MPCP discover®ister

Support authentication Mac/Loid/Mac+Loid

Support Triple Churning

Support DBA bandwidth

Support auto-detecting, auto-configuration, and auto firmware upgrade

Support SN/Psw/Loid/Loid+Psw authentication

Alarm

Support Dying Gasp

Support Port Loop Detect

Support Eth Port Los

LAN

Support Port rate limiting

Support Loop detection

Support Flow control

Support Storm control

VLAN

Support VLAN tag mode

Support VLAN transparent mode

Support VLAN trunk mode(max 8 vlans)

Support VLAN 1:1 translation mode(≤8 vlans)

Multicast

Support IGMPv1/v2/Snooping

Max Multicast vlan 8

Max Multicast Group 64

QOS

Support 4 queues

Support SP and WRR

Support 802.1P

L3

Support IPv4/IPv6

Support DHCP/PPPOE/Static IP

Support Static route

Support NAT

Management

Support CTC OAM 2.0 and 2.1

Support ITUT984.x OMCI

Support WEB

Support TR069

Support TELNET

Support CLI
