| Model Version | GP10 1.0 |
| CPU | CPU Details | 300 MHz MIPS |
| Memory/Storage | Flash/ROM | 8 MB (64 Mbit ) NOR |
| | DDR/RAM | 64 MB (512 Mbit) DDR2 |
| xPON | Protocols | - GPON (ITU G. 984 standard | Class B+)
- EPON (802.3ah)
|
| | Speed | - GPON: 2.488 Gbps Downstream / 1.244 Gbps Upstream
- EPON: 1.25 Gbps Downstream / Upstream
|
| | Wavelength | TX: 1310 nm
RX: 1490 nm |
| | Max Transmission Distance | 20 km |
| Interfaces | SC/APC Port | 1 |
| | Gigabit RJ45 Ports | 1 |
| | LED | |
| | Physical Buttons | Reset Button |
| | Power Input | DC Jack |
| Power | Power Methods | DC |
| | DC | 12V 1A |
| | Power Adapter | Input: 100-240V~, 50/60 Hz
Output: 12V⎓1A |
| Reliability | Environment | Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing |
| Certifications | FCC, CE |
| Mechanical | Installation | |
| | Dimension | 82×82×27 mm
3.23×3.23×1.06 inches |
| Package Content | - GP10
- Power Adapter
- Ethernet Cable
- Installation Guide
|
| Ordering Information | Retail Package Dimension | 106×89.5×85 mm
4.17×3.52×3.35 inches |
| Mechanical | Casing Material | Plastic |
| Ordering Information | Units per Carton | 20 |
| | Carton Dimension | 459×230×205 cm
180.71×90.55×80.71 inches |
