| Mechanical |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 3.9 kg (8.6 lb) |
| Enclosure materials | Aluminium CNC, SGCC steel |
| Mount material | SGCC steel |
| Hardware |
| Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
| System memory | 4 GB DDR4 |
| On-board storage | 16 GB eMMC |
| Management interface | Ethernet
Bluetooth |
| Networking interface | (8) LAN: GbE RJ45 ports
(1) WAN: GbE RJ45 port |
| SFP+ interface | (1) LAN: 10G SFP+
(1) WAN: 10G SFP+ |
| IDS/IPS throughput | 3.5 Gbps *
* Measured with iPerf3. |
| Power method | (1) Universal AC Input, 100—240V AC, 50/60 Hz
(1) USP-RPS DC input |
| Power supply | AC/DC, internal, 50W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 33W |
| ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Operating temperature | -10° to 40° C (14° to 104° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features |
| Performance | Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting |
| Next-generation security | Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall |
| Advanced networking | License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and UID VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support |
