| Hardware Features | Highlights | CPU: 880 MHz Dual-Core Processor |
| Flash: 16 MB (128 Mbit) |
| DDR: 128 MB (1 Gbit) |
| Interface | 1× Gigabit Ethernet Port (PoE In) |
| 1× Reset Button |
| 1× DC Jack |
| Power Supply | 802.3af/at PoE |
| 24-57 V Passive PoE (+4,5pins; -7,8pins) |
| 12 V ⎓ 1A DC |
| Power Consumption | Idle: 4 W |
| PoE Max: 11 W DC Max: 7.5 W |
| Dimensions ( W×D×H ) | 232×232×57.1mm |
| Antenna Type | 4× Internal Omni-directional Antennas |
| Mounting | Ceiling/Wall Mounting (Kit included) |
| Wireless Function | Wireless Standards | Wi-Fi 5 (802.11ac/n/g/b/a) |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 5 GHz: Up to 867 Mbps |
| 2.4 GHz: Up to 300 Mbps |
| Channel Width | 20/40/80 MHz |
| Wireless Functions (Features with * require a Cudy AC as the gateway, Cudy AC is coming soon in late 2023) (Features with △ require a Cudy Mesh unit/Mesh router or AC as the gateway with firmware newer than 15.28) | Multiple SSID* |
| Captive Portal* |
| Seamless Roaming Mesh△ |
| Self-Organizing Mesh△ |
| Band Steering* |
| Auto Channel Optimization* |
| Enable/Disable Wireless Radio |
| Transmit Power Control |
| QoS (WMM) |
| MU-MIMO |
| Beamforming |
| Rate Limit |
| Reboot Schedule |
| Wireless Schedule |
| Wireless Encryption | WPA-PSK |
| WPA2-PSK |
| WPA-PSK/WPA2-PSK |
| Security (Features with * require a Cudy AC as the gateway, Cudy AC is coming soon in late 2023) | IP/MAC Filtering |
| AP Isolation* |
| Operating Modes | Wireless Access Point Mode |
| Wireless Router Mode |
| Wireless Extender Mode |
| WISP Mode |
| Package Content | Access Point |
| DC Adapter |
| Mounting Kit |
| Installation Guide |
| Environments | Operating Temperature: 0~40 °C (32~104 °F) |
| Storage Temperature: -40~70 °C (-40~158 °F) |
| Operating Humidity: 10~90% RH non-condensing |
| Storage Humidity: 5~90% RH non-condensing |
| System Requirements | Windows, MAC OS, NetWare, UNIX, or Linux |
| Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other Javascript-enabled browser |
| A fiber/cable/DSL Modem, or other devices providing wired internet |
| Subscription with an internet service provider for internet access |
| A power socket for AC power supply, or PoE power supply |
| Advanced business AP features require a Cudy AC as the gateway, Cudy AC is coming soon in late 2023. Mesh features require a Cudy Mesh unit/Mesh router or AC as the gateway with firmware newer than 15.28. |
