Panel type VA
Panel size 23.8 ”
Aspect ratio 16:9
Gauge(mm) 0.2745*0.2745
Resolution 1920×1080
Luminance(cd/m2
) 250
Contrast 3000:1
Response time(ms) 14
Refresh rate 60HZ
Colouration 16.7M
Display size(mm) 527.04(H)×296.46(V)
Viewpoint(H/V) 178 °(H) / 178 °(V)
Video input HDMI*1, VGA*1
Video output N/A
Audio input Yes
Audio output N/A
Control interface N/A
Speaker Yes
OSD(Language)
12 countries
(English、Deutsch、Francaise、Español、Italiano、Nederlands、中文、日本、
한국어、Dansk、Português、Turkish )
Wall mounting holes
(mm)
100*100
Wall mounted threads 4-M4 Screw hole
Input Voltage DC 12V,2A
Typical power
consumption(W)
≤24
Standby power
consumption(W)
≤0.5
Operating temperature 0～40℃
Operating humidity 20%～85% RH Non-Condensing
Storage humidity 10%～90% RH Non-Condensing
Bare metal size(mm) 540.4(W)×419.1(H)×190(D)
Package Size(mm) 601(W)×400(H)×145(D)
Net weight(Kg) 2.9
Gross weight(Kg) 4.4
