| INPUT |
| Dual Input | no |
| Rated power | 10000 VA |
| Voltage | 380-400-415 Vac (3W+N+PE) 220-230-240 Vac (1W+N+PE) |
| Voltage tolerance | 242 Vac < Vin < 478 Vac @50% LOAD / 318 Vac < Vin < 478 Vac @ 100% LOAD (3W+N+PE) 140 Vac < Vin < 276 Vac @50% LOAD / 184 Vac < Vin < 276 Vac @ 100% LOAD (1W+N+PE) |
| Frequency | 50/60 Hz 5 Hz |
| Frequency tolerance | 50 Hz 20% / 60 Hz 20% |
| Power factor | >0.98 |
| Current distorsion | ?5% |
| BY PASS |
| Voltage tolerance | 180264 Vac (selectable in Economy Mode and SMART ACTIVE Mode) |
| Frequency tolerance | Selected frequency 5% (user configurable) |
| Number phases | 1 |
| OUTPUT and INVERTER OUTPUT |
| Rated power | 10000 VA |
| Active power | 10000 W |
| Crest factor (Ipeak/Irms) | 3 : 1 |
| Waveform | Sinewave |
| Frequency | 50/60 Hz selectable |
| Voltage distortion with distorcing load | <6% |
| Voltage distortion with linear load | <3% |
| Inverter efficiency at rated load | 95% % |
| OVERLOAD TIMES |
| 100% < Load < 110% | activates the bypass after 10 min Continues to work on by-pass |
| 110% < Load < 133% | activates the bypass after 1 min shut down after 1 hour |
| 133% < Load < 150% | activates the bypass after 5 s shut down after 10 min |
| Load > 150% | activates the bypass instantaneously shutdown after 3 s (load > 150%) shutdown after 2 s (load > 200%) |
| BATTERIES |
| Type | VRLA AGM lead, maintenance-free |
| Typical recharge time | 46 h |
| OPTIONS |
| Parallel kit (to order with the UPS) | Yes |
| ENVIRONMENTAL |
| Altitude max | 1000 m at nominal power (-1% power for every 100 m above 1000 m) 4000 m maximum |
| Color | Black RAL 9005 |
| Communication | USB / DB9 with RS232 and contacts / Slot for communication interface |
| Safety compliance | EN 62040-1:2008; EN 62040-1/EC:2009; EN 62040-1/A1:2013 and Directive 2014/35/EU |
| EMC conformance | EN 62040-2 and Directive 2014/30/EU |
| Accessories provided | USB cable |
| Protection rating | IP20 |
| Surge capability | 1 VDR x 300 Joules |
| Marks | CE |
| Protections | Overload – short-circuit – overvoltage – undervoltage – temperature – low battery |
| AC/AC efficiency | 95% |
| Line-Interactive/Smart Active efficiency | 98% |
| Noise (at 1 m) | <48 dBA |
| Operating temperature | 0 40 C |
| Relative humidity | 5 – 95% no condensing |
| Output sockets | Terminal block + 2 IEC 320 C13 |
| DATA |
| Weight | 84 kg |
| Dimensions (h w d) | 698 x 500 x 250 mm |
| Input phases | 1 |
| Output phases | 1 |
