AC Mode |
Description | S650BX |
Input Voltage | 140V – 280V AC |
Input Frequency | 50Hz 5% |
Output Voltage | 220V 10% |
Output Power | 650VA |
Nominal RMS Input Current | 2.5A |
Inverter Mode |
Output Voltage | 220V 5% |
Output Wave form | PWM Simulated Sine wave |
Output Frequency | 50Hz 1% |
Max Output Current | 1.7A |
Load Backup | 20 minutes, depends on load and model |
Low Battery Automatic Cutoff and Automatic Restart | Yes |
Others |
Battery Type | Sealed Lead-acid maintenance-free |
Battery Quantity | 1 * 12V/8.2AH |
Recharge Time | 90% capacity after 8 hours |
Short Circuit | Fuse Current Limited Cut-off |
Load Power Factor Range | 0.95-1(AC Normal) |
UPS Efficiency For Rated Output Load Under Specified Conditions | 90% |
Transfer Times | 0.2ms |
Surge and Noise Protection | Yes |
Capacity(Joule) | 520 |
Fuse AC | 6.3A |
Surge | IEEE 587 Category A, Varistor Clamping |
CE-LCD EMS | Yes |
Input Connector | (1) IEC 320 C14 |
Outlets | (3) Schuko |
