Features
* Support HDMI 1.4/HDCP1.4;
* Support local loop-out ;
* Support 120m long distance transmission.
* Low power consumption, low temperature and high safety;
* Both the TX and RX support 3.5MM left and right audio output;
* Support IR control;
* Support USB mouse and keyboard extension;
Specifications:
Length of CAT5e/CAT6 cable between Rx and TX：120 meters
HDMI Input：4k/1080p/720p/576p/576i/480p/480i
HDMI Output ：4k/1080p/720p/576p/576i/480p/480i
Max bandwidth ：340MHz
Max baud rate：3×3.4Gbps
Input video signal：0.5~1.5Volts p-p
Output DDC signal ： 5Volts p-p (TTL)
Input HDMI cable distance ：≤10m AWG26 HDMI standard cable
Output HDMI cable distance ：≤10m AWG26 HDMI standard cable
TX Max working current：350mA
RX Max working current ：200mA
Power adapter format ：Input:AC (50HZ, 60HZ) 100V-240V;
Output: DC5V/1A
Operating Temperature range ：(-15 to +55℃)
Operating Humidity range ： 5 to 90%RH (No Condensation)
Dimension (L x W x H) ：107x105x27.3 (mm)
TX Weight ：499g RX Weight ：494g
The Package includes:
1. TX Extender 1pcs
2. RX Extender 1pcs
3. IR cable 1pair
4. 12V/2A DC Power adapter 2pcs
5. User Manual 1pcs
